LS Electric Air Circuit Breaker (ACB): The Smart Choice for Safe, Reliable Power Distribution in India


Introduction

Every industrial facility, commercial complex, and data centre in India runs on one non-negotiable requirement: uninterrupted, safe power. A single unplanned electrical fault can halt production lines, damage critical equipment, or worse, put people at risk. This is exactly the kind of failure an Air Circuit Breaker (ACB) is engineered to prevent.


At the heart of India's growing demand for smarter, safer electrical infrastructure is LS Electric, a global power and automation solutions brand with over five decades of engineering heritage. Its Susol and Metasol ACB ranges combine rugged mechanical protection with intelligent digital monitoring — giving facility managers, panel builders, and electrical engineers the confidence that their power system is protected around the clock.

In this article, we break down what an ACB is, why LS Electric's ACBs stand out, and how the built-in smart monitoring feature — accessible through the LSE SmartViewer app — lets you check your breaker's status in a single glance, or "view once," from your smartphone.


What Is an Air Circuit Breaker (ACB)?

An Air Circuit Breaker is a protective switching device used in low-voltage power distribution systems, typically installed at the main incomer, bus-tie, or generator output of an electrical panel. It uses air as the arc-extinguishing medium to safely interrupt current when it detects an overload, short circuit, or ground fault.


ACBs are built for high current-carrying capacity and are commonly rated from 630A up to 6300A, making them the backbone of protection for:

  • Industrial plants and manufacturing units

  • Commercial complexes and shopping malls

  • Data centres

  • Hospitals and airports

  • Power plants and substations

  • Renewable energy installations (solar PV, wind, energy storage)



LS Electric's ACB Range: Susol & Metasol

LS Electric offers two globally certified ACB series designed to suit different budgets and performance needs, both compliant with IEC 60947-2.


Susol ACB — Premium Performance

The Susol series is LS Electric's flagship, high-performance ACB line, built for applications where maximum breaking capacity and compact panel design matter most.

  • Rated current: 630A – 6300A, 3 & 4 pole

  • Breaking capacity (Ics): up to 150kA at 500V AC

  • Rated operating voltage (Ue): 690V

  • Rated insulation voltage (Ui): 1000V

  • Rated impulse withstand voltage (Uimp): 12kV

  • N-phase current conducting capacity: 100%

  • Available in 3 compact frame sizes: 2000AF / 4000AF / 6300AF

  • "Arc Space Zero" arc-box design for compact panel integration

  • Certified for marine use (LR, ABS, DNV, KR, BV, GL, RINA, NK) and nuclear applications (KEPIC)


Metasol ACB — Reliable Value

The Metasol series delivers dependable protection with fundamental smart features at a more accessible price point, available in two variants:

  • Metasol AN — upto 1600AF frames, breaking capacity up to 65kA

  • Metasol AS — upto 6300AF frames, breaking capacity up to 120kA

  • Same IEC 60947-2 compliance and 690V rated operating voltage as Susol

  • Ideal for cost-sensitive projects that still demand certified reliability


Built to Last

Both series are engineered for long service life:

  • Mechanical life cycle: 20,000 operations

  • Electrical life cycle: 5,000 operations

  • Maximum total breaking time: under 25ms (within Icw) / under 75ms (above Icw)

  • Maximum closing time: 80ms



The Intelligence Inside: Smart Trip Unit (STU)


What truly sets modern LS Electric ACBs apart is the Smart Trip Unit (STU) — the digital brain of the breaker. Available in four tiers (N / A / P / S type), it moves the ACB from a purely mechanical safety device into an intelligent monitoring and diagnostic tool.

Key STU capabilities include:

  • Metering-class accuracy — 0.5% for current and voltage, Class 1.0 for power (S type)

  • Comprehensive protection — overload, short-circuit, ground fault, over/under voltage, over/under frequency, phase unbalance, and reverse power

  • Zone Selective Interlocking (ZSI) — isolates only the breaker closest to a fault, minimizing downstream disruption

  • Energy Reduction Management System (ERMS) — reduces arc-flash energy during maintenance for on-site engineer safety

  • Self-diagnosis — flags CT disconnection, contact wear (alert at over 80% wear), internal overheating, and battery-low conditions before they cause failures

  • Event & fault logging — stores up to 255 system events, 127 fault events, and 6 detailed fault waveforms

  • Rating plug — change the rated current setting without replacing the CT, saving cost and downtime

  • 3.5" colour graphic touchscreen (P & S type) — real-time measurements, load factor, vector diagrams, and waveform display directly on the breaker


"View Once" — Smart Monitoring with LSE SmartViewer

One of the most practical advantages of the S-type Smart Trip Unit is how easily engineers can check breaker health without opening a panel or connecting a laptop. This is made possible through LSE SmartViewer, LS Electric's official mobile monitoring app, paired with built-in NFC and Bluetooth (BLE) connectivity on the breaker.

Here's what makes it feel like a genuine "view once and know everything" experience:

  • Tap-to-view with NFC: Simply hold your smartphone near the breaker to instantly read the last trip information — even when the breaker is unpowered. No login, no cables, no panel access required.

  • Full live access with Bluetooth: While the breaker is powered, connect via BLE (within a 4-metre range) to view real-time measurements, device settings, status, event logs, and stored trip waveforms — all on your phone.

  • Settings backup and transfer: Copy configuration settings from one device and apply them to another, streamlining commissioning across multiple breakers.

  • On-demand documentation: The app can scan a matrix code on the device to instantly pull up the relevant manual — useful for maintenance teams working across mixed breaker fleets.

For facility managers, this means faster fault diagnosis, safer maintenance (no need to de-energize panels just to check status), and less time spent tracking down paper manuals — all from a single tap of a smartphone.



Compact ACB


A compact ACB delivers the same current rating and breaking capacity as a standard ACB, but within a significantly smaller frame size. This is made possible through advanced engineering — such as improved arc-quenching chambers and optimized internal component layout (for example, LS Electric's "Arc Space Zero" design used in the Susol series).


  • Rated current: 1600A, 3 & 4 pole

  • Breaking capacity (Ics): up to 50kA at 500V AC

  • Rated operating voltage (Ue): 690V

  • Rated insulation voltage (Ui): 1000V

  • Rated impulse withstand voltage (Uimp): 12kV

  • N-phase current conducting capacity: 100%

  • Available in just 3 compact frame sizes: 1600AF

  • "Arc Space Zero" arc-box design for reduced panel space

  • Best suited for space-constrained installations like data centres, commercial buildings, and panel retrofits


Key characteristics:

  • Smaller footprint for the same current/breaking capacity rating

  • Enables more compact, space-efficient switchboard design

  • Reduces panel and switchroom real estate requirements

  • Often paired with smart digital features (like a Smart Trip Unit) since compact ACBs are typically part of newer product generations

  • Ideal where space and layout flexibility matter as much as protection performance


Best suited for: Modern commercial buildings, data centres, retrofits, and any installation where switchroom space is limited or costly — situations increasingly common in urban Indian construction and infrastructure projects.


High Voltage ACB — Susol AV/AW Series (up to 1150Vac)


For applications operating beyond standard 690V systems — such as solar PV, ESS, and wind power installations, especially in high-altitude or harsh environments — LS Electric offers the Susol AV/AW series, rated up to 800V / 900V / 1000V / 1150V AC.


  • Rated operational voltage (Ue): up to 1150V AC (AV series) / up to 900V AC (AW series)

  • Rated insulation voltage (Ui): 1250V (AV) / 1000V (AW)

  • Rated impulse withstand voltage (Uimp): 12kV

  • Poles: 3 & 4 pole

  • Frame sizes: D-Frame (up to 2000AF), E-Frame (up to 4000AF), G-Frame (up to 6300AF)

  • Rated current: 200A – 6300A

  • Breaking capacity (Icu):

    • AV-D (up to 2000AF): 30kA @1150V / 42kA @1000V / 50kA @900V-800V

    • AV-E (up to 4000AF): 50kA @1150V / 65kA @1000V / 75kA @900V-800V

    • AV-G (up to 6300AF): 65kA @1150V / 85kA @1000V-900V-800V

  • Mechanical life cycle: 20,000 operations (D/E Frame) / 10,000 (G-Frame)

  • Electrical life cycle: 1,000 operations (D/E Frame) / 500 (G-Frame)

  • Equipped with the new Trip Relay (STU) offering 0.5% current/voltage accuracy and Class 1.0 power accuracy

  • AV series applicable for IT systems up to 1000V AC

  • Certified per IEC 60947-2


Also available — Susol Compact ACB up to 800Vac (AW-C series):

  • Frame sizes: AW-08C, AW-16C (up to 1600AF)

  • Rated current: 400A – 1600A

  • Breaking capacity (Icu): 40kA @800V

  • Compact dimensions (as low as 256mm wide, 3-pole) for space-constrained high-voltage installations


Best suited for: Solar PV plants, energy storage systems (ESS), wind power facilities, and installations in high-altitude or harsh environmental conditions requiring protection above standard 690V AC systems.



Built for India's Growing Power Demands

LS Electric ACBs are engineered to support the sectors driving India's infrastructure and energy growth:


  • Manufacturing & industrial plants — reliable main incomer protection to prevent costly downtime

  • Data centres — selective coordination (via ZSI) to isolate faults without disrupting critical uptime

  • Commercial real estate — compact panel design that saves valuable switchroom space

  • Renewable energy — LS Electric's high-voltage AV/AW series ACBs support solar PV, wind, and energy storage systems up to 1150V AC, an increasingly important segment as India scales up renewable capacity


LS Electric operates in India through LS Electric India Pvt. Ltd., with a growing local presence to support project consultation, distribution, and after-sales service across the country.


Why Choose LS Electric ACBs?

What You Get

Why It Matters

IEC 60947-2 certified (Susol & Metasol)

Meets international safety and performance standards

Breaking capacity up to 150kA

Confident protection even in high-fault-current installations

Compact, single-size-per-frame design

Saves panel space and simplifies switchgear design

Smart Trip Unit with metering-class accuracy

Reduces the need for separate metering devices

NFC/BLE + LSE SmartViewer app

Faster diagnostics, safer maintenance, less downtime

Global certifications (marine, nuclear)

Proven reliability across the most demanding industries
